Worm & Wheels

• Various machines with sets mating up to 32″ centres

Gear Hobbing

• One – Modul 3150 (capacity extended to 4250mm dia x 30 MOD) with single indexing and internal cutting head capabilities
• One – Modul ZFWZ 200/3 – which has 2 cut cycle, single index and crowning facilities, capable of cutting gears up to 2 metre dia. x 800mm face up to 25 MOD
• One – ZFW10 Precision Gear Hobber, producing gears up to DIN grade 6 and up to 16 MOD, 1500mm dia. x 1000m face width. Equipped to barrel hob and single index
• One – Pfauter P900 (max 900mm x 16 MOD)
• One – Modul ZFWZ 800 (mas 900mm x 16 MOD)
• One – Pfauter P630 (2 cut cycle & crowning max 630mm x 10 MOD)
• One- Pfauter P400 (400mm x 10MOD)
• One Tos 71 (750mm x 10 MOD)
• One – Liebherr ET 1200 (1250mm x 32 MOD)
• One Heckert ZFWVG (250mm dia x 2 metre x 8 MOD)
• One Heckert GFLV (250mm dia x 3 metre x 8 MOD)

Bevel Gears

• One – G & E 60S2 Bevel Gear Rougher
• Seven – 24A Gleason Coniflex Bevel Generator (900mm dia x 25MOD)
• One – 154 Gleason Bevel Planer (max 1500mm dia x 40 MOD)
• Three – 54 Bevel Planer (max 150mm dia x 40 MOD)
• One – 12″ Gleason straight Bevel Generator (max 600mm dia x 8 MOD)
• One – 28″ Hypoid Gear Generator
• One – G & E 60B

Gear Shaping

• One – Sykes 5E (1500mm x 16 MOD) equipped with straight & 30 degree double helical guides
• Two – Sykes 3C (1000mm x 10 MOD) equipped with straight & 30 30 degree double helical guides
• One – Drummond Maxicut 3A
• One – Drummond Maxicut 2A
• One – MAAg 8H 180/300 (300mm x 32 MOD) max face width 450 (equipped with STD internal & oblique cutting heads)
• One – Sunderland 16 (800mm x 14 MOD)
